Aquaflame Soldering Torch Model 800

The Aquaflame 800 is the mid-range model in the Aquaflame line. It puts out 120 L/hr of oxy-hydrogen gas and supports a second torch station — add the second operator kit (830-1084, sold separately) when you need two people working at once. The broader tip range, down to #18, handles heavier soldering and brazing jobs that the 500 can't take on. Same water-based operation, no gas cylinders required.

Features

• Runs on deionized water and electrolyte solution. No gas cylinders or pressure tanks required!
• Reaches 3,300°C — handles platinum, gold, silver, and stainless steel
• Supports up to 2 simultaneous operators (second operator kit sold separately)
• 7 tip sizes (#18–#24, 0.90–0.31mm bore)
• Built-in flashback arrestor for continuous-use safety
• 2-year warranty

Required Chemicals

• Electrolyte: KOH dry crystals, Item 8300044 (600g). One bottle per fill.
• Booster fluid: MEK, Item 8300042 (1 qt).
• Aquaflame systems are approved for MEK booster and dry KOH electrolyte only. Do not use methanol-based flux (such as OKAI HF-9) or premixed liquid electrolytes (such as OKAI HF-8) — they are not compatible with Aquaflame hoses and seals and will cause damage.

Recommended Add-On: Setup Kit

The Hydrogen Torch Setup Kit (Item 8301085) includes measuring beakers, a graduated cylinder, a stirring rod, safety goggles, and disposable gloves — everything needed for safe electrolyte preparation.
